RTL8201F-VB-CG Ethernet IC Single-Chip Single-Port 10/100Mbps Ethernet PHY Ceiver With Auto Mdix

RTL8201F-VB-CG Ethernet IC Single-Chip Single-Port 10/100Mbps Ethernet PHY Ceiver With Auto Mdix

Product Description Of RTL8201F-VB-CG
RTL8201F-VB-CG is single-chip/single-port 10/100Mbps Ethernet PHYceivers that support:
MII (Media Independent Interface)
RMII (Reduced Media Independent Interface)

RTL8201F-VB-CG implement all 10/100M Ethernet Physical-layer functions including the Physical Coding Sublayer (PCS), Physical Medium Attachment (PMA), Twisted Pair Physical Medium Dependent Sublayer (TP-PMD), 10Base-TX Encoder/Decoder, and Twisted-Pair Media Access Unit (TPMAU). The RTL8201F-VB-CG support auto MDIX.

A PECL (Pseudo Emitter Coupled Logic) interface is supported to connect with an external 100Base-FX fiber optical transceiver. The chip utilizes an advanced CMOS process to meet low voltage and low power requirements. With on-chip DSP (Digital Signal Processing) technology, the chip provides excellent performance under all operating conditions.

In addition, the RTL8201F-VB-CG can be used in any embedded system with an Ethernet MAC that needs a UTP physical connection or Fiber PECL interface to an external 100Base‑FX optical transceiver module.

Feature Of RTL8201F-VB-CG
Supports IEEE 802.3az-2010 (EEE)
100Base-TX IEEE 802.3u compatible
10Base-T IEEE 802.3 compatible
Supports MII mode
Supports RMII mode
Full/half duplex operation
Twisted pair or fiber mode output
Supports Auto-Negotiation
Supports power down mode
Supports Link Down Power Saving
Supports Base Line Wander (BLW) compensation
Supports auto MDIX
Supports Interrupt function
Supports Wake-On-LAN (WOL)
Adaptive Equalization
Automatic Polarity Correction
provide two network status LEDs
Supports 25MHz external crystal or OSC
Supports 50MHz external OSC Clock input
Provides 50MHz clock source for MAC
Low power supply 1.1V and 3.3V; 1.1V is generated by an internal regulator
11µm CMOS process
32-pin MII/RMII QFN Green package

Applications Of RTL8201F-VB-CG
DTV (Digital TV)
MAU (Media Access Unit)
CNR (Communication and Network Riser)
Game Console
Printer and Office Machine
DVD Player and Recorder
Ethernet Hub
Ethernet Switch
