MKE14F256VLL16 Microcontroller MCU Kinetis 168MHz Arm Cortex-M4 Microcontrollers With CAN

MKE14F256VLL16 Microcontroller MCU Kinetis 168MHz Arm Cortex-M4 Microcontrollers With CAN

Product Overview Of MKE14F256VLL16
MKE14F256VLL16 MCUs is the high end series MCUs in Kinetis E family, providing robust 5V solution with the high performance Arm® Cortex®-M4 core running at up to 168 MHz. The Kinetis KE1xF MCU family also integrates CAN 2.0B compliant FlexCAN provides high reliable serial communication interface for industry applications, and rich suite of communication interfaces including LPUARTs, LPI2Cs, LPSPIs, and FlexIO.

Specifications Of MKE14F256VLL16

Features Of MKE14F256VLL16
Up to 168MHz Cortex-M4 core supporting a broad range of processing bandwidth requirements while maintaining excellent cost-effectiveness, easy to use packages and a wide range of memory densities
Enhanced robust IOs make sure the high performance under noisy environment
Flextimer featured 8ch PWM supports 3-phase motor control with dead time insertion and fault detect
1MSPS 12b ADC with up to 16ch input per module, provides fast sampling rate for prompt data conversion and storage
Analog comparator for fast response to external analog change
Programmable delay block with flexible trigger system providing various interconnections for on chip modules, ADC, DAC, Flextimers, ACMP, etc.
CAN 2.0B compliant FlexCAN provides high reliable serial communication interface for industry applications
FlexIO provides flexibility for serial communication interface implementation
Boot ROM provides on chip boot code and serial port drivers that could save flash space and provide flexible boot options and in system programming support
Packages with big pin pitch make manufacture easy with high yield
8KB Cache could improve the code and data access efficiency
Featuring digital signal processing capabilities with floating point unit offering outstanding computational power for control algorithms, sensor data processing, audio processing, among others, while increasing math accuracy and reducing code size
MPU for memory protect and code safety
Faster time to market with comprehensive enablement solutions, including SDK (drivers, libraries, stacks), IDE, bootloader, RTOS, online community and more

Applications Of MKE14F256VLL16
Automotive
Heating Ventilation and Air Conditioning (HVAC)
Motorcycle Engine Control Unit (ECU) and Small Engine Control
Consumer
Air Conditioning (AC)
Hearables
Major Home Appliances
Robotic Appliance
Small and Medium Appliances
Industrial
3-Phase AC Induction Motor
Automatic Vehicle Identification
Brushless DC Motor (BLDC) Control
Building Safety Detectors
Electricity Metering
Motion Control and Robotics
Motor Drives
Permanent Magnet Synchronous Motor (PMSM)
Power Grid Converter
Smart Lighting
Smart Power Socket
Smart Watch and Wristband
Surround View
Transport Ticketing
